 Features |
 Single Door Controller with Anti Pass Back |
| Supports Pin and Card (EM or Mifare or or CEPAS {EZ-Link/NETS FlashPay/Concession Cards}) reading |
| Built-in http Server. System Management via Web Browser |
Standalone or Network Mode |
Real Time Access Monitor |
Dual authentication method: Card and Password |
On Screen Display manual |
| Weigand Output Support |
| Selectable Time Zone for Pin/Card / Lock Release / Exit Button |
| Supports 50 Holidays, Internet Time Server, 40 Sets Function Key Setting, 32 Departments, 32 Designations, 64 Time Zones, 32 Groups |
| Also serves as time attendance station |
 Specifications |
Dimensions: 130mm (L) x100mm (W) x 52mm (H) |
| Verification Methods: RFID or Password or RFID+Password |
| Capacty: 5000 users, expandable to 20,000 users |
| Log Data: 32768 transactions |
| Display: LCD 128x64 dots, 3 LEDs |
| Card Reading Distance: up to 65mm |
| Comm. Interface: TCP/IP, 10/100M, auto crossing |
| Reader Interface: Wiegand |
| Built-in RF Reader: EM125KHz or Mifare 13.56MHz or CEPAS (EZ-Link/NETS FlashPay/Concession Cards) |
